Renogy 300A Battery Shunt
High-precision battery monitoring device with Bluetooth
AU$99.00
Upgrade your energy management with the Renogy Battery Shunt 300—engineered for precise monitoring of battery status and power consumption. Featuring advanced Bluetooth connectivity, this shunt allows you to easily track and analyze real-time data from your mobile device, ensuring optimal performance for off-grid and solar energy systems. Compact and durable, the Renogy Battery Shunt 3000 seamlessly integrates into your setup, providing reliable insights and helping to extend the life of your batteries. Available in a sleek black finish and designed for effortless installation, it’s the perfect choice for energy enthusiasts seeking convenience and dependability.
Package Includes
battery shunt Only option
Battery Shunt 300 x 1
Quick Guide x 1
Mounting Screws x 3
B+ Wires (1 m) (22 AWG) × 2
Temperature Sensor (1.5 m) × 1
Specifications
ELECTRICAL DATA | |
|---|---|
Product Name: Smart Shunt 300 | Model Name: RSHST-B02P300-G1 |
Power Supply: 8 - 120 VDC | Power Consumption: <0.1 W |
Communication: Bluetooth LE and BLE Mesh | Max continuous current: 300A |
Max peak current: 500A(<10s) | Current accuracy: ±1% |
Current Resolution: 0.01 A | Battery Capacity: 1 - 6500Ah |
Voltage Input Range: 8 - 60V | Voltage input resolution: 10 mV |
Temperature sensor range: -20~80℃ | Temperature sensor accuracy: ±1% |
Operating Temperature: -4℉~122℉(-20 ℃ to 50 ℃) | Operating Humidity: 0% to 95% RH |
Operating Altitude: Less than 2000m above sea level | Installation: mounted on the wall |
Battery connection: M10 bolts | Weight: 0.57lb (260g ) |
Dimensions: 5.27 x 3.82 x 1.22 inch (134 x 97 x 31 mm) | Warranty: 1 year |
Certifications: CE, FCC ID,IC ID,RCM,TSCA, RoHS,UN38.3,TELEC | |
